Additional standard joystick module for the SRH remote control. The standard joystick is mounted on the left side of the SRH remote control.NOTEBoth controllers can be installed by the operator himself, no additional service is required.For 360 EVO and SRH-3 and SRH-360 remote control panel.
The Broadcast Joystick is a high-resolution 3-axis controller for the SRH remote control. The Broadcast Joystick offers a highly precise and tactile, optimized control of the pan and tilt axis of the remote head. The third axis can be used to control zoom or the roll axis.For 360 EVO and SRH-3 and SRH-360NOTETo complete the initial order, at least one of the mandatory joystick sets must be ordered. The controller can be installed by the operator themselves, no additional service is required.
The ARRI Digital Encoder Head is the perfect way to intuitively control the Stabilized Remote Head 360 EVO and SRH-3 and SRH-360. The DEH-1 was specially manufactured according to ARRI specifications, with features such as special damping performance and adjustable pan bars. The DEH-1 uses LBUS communication to control the 360 EVO and SRH-3 and the SRH-360, especially for broadcast applications, but the LBUS also enables the use of Master Grips and the OCU-1 to control focus and zoom. With the DEH-1, you can control all functions of the remote head, as well as focus and zoom, using a single cable.NOTE Only LBUS communication. No cables included.
The ARRI Digital Encoder Head is the perfect way to intuitively control the Stabilized Remote Head 360 EVO and SRH-3 and SRH-360. The DEH-1 was specially manufactured according to ARRI specifications, with features such as special damping performance and adjustable pan bars. The DEH-1 uses LBUS communication to control the 360 EVO and SRH-3 and the SRH-360, especially for broadcast applications, but the LBUS also enables the use of Master Grips and the OCU-1 to control focus and zoom. With the DEH-1, you can control all functions of the remote head, as well as focus and zoom, using a single cable.includes:K2.0022594 1x DEH-1 Digital Encoder HeadK2.0009363 1x Master Grip Left Wheel MLW-1K2.0009493 1x Master Grip Right Rocker MRR-1K2.0012919 2x Handgrip Pan Bar Adapter 20mmK2.0006752 1x Cable LBUS - LBUS (0.8m/2.6ft)K2.0006753 1x Cable LBUS - LBUS (1.5m/5ft)NOTELeft side: Master Grip Wheel (focus)Right side: Master Grip Zoom Rocker (zoom)
The ARRI Digital Encoder Head is the perfect way to intuitively control the Stabilized Remote Head 360 EVO and SRH-3 and SRH-360. The DEH-1 was specially manufactured according to ARRI specifications, with features such as special damping performance and adjustable pan bars. The DEH-1 uses LBUS communication to control the 360 EVO and SRH-3 and the SRH-360, especially for broadcast applications, but the LBUS also enables the use of Master Grips and the OCU-1 to control focus and zoom. With the DEH-1, you can control all functions of the remote head, as well as focus and zoom, using a single cable.includes:K2.0022594 1x DEH-1 Digital Encoder HeadK2.0020002 1x Operator Control Unit OCU-1 Basic SetK2.0020003 1x OCU-1 Rosette BracketK2.0009490 1x Master Grip Left Rocker MLR-1K2.0012919 2x Handgrip Pan Bar Adapter 20mmK2.0006752 1x Cable LBUS - LBUS (0.8m/2.6ft)K2.0006753 2x Cable LBUS - LBUS (1.5m/5ft)NOTELeft side: Master Grip Zoom Rocker (zoom) Right side: OCU-1 (focus)
The ARRI Digital Encoder Head is the perfect way to intuitively control the Stabilized Remote Head 360 EVO and SRH-3 and SRH-360. The DEH-1 was specially manufactured according to ARRI specifications, with features such as special damping performance and adjustable pan bars. The DEH-1 uses LBUS communication to control the 360 EVO and SRH-3 and the SRH-360, especially for broadcast applications, but the LBUS also enables the use of Master Grips and the OCU-1 to control focus and zoom. With the DEH-1, you can control all functions of the remote head, as well as focus and zoom, using a single cable.includes:K2.0022594 1x DEH-1 Digital Encoder HeadK2.0020002 1x Operator Control Unit OCU-1 Basic SetK2.0020003 1x OCU-1 Rosette BracketK2.0009493 1x Master Grip Right Rocker MRR-1K2.0012919 2x Handgrip Pan Bar Adapter 20mmK2.0006752 1x Cable LBUS - LBUS (0.8m/2.6ft)K2.0006753 2x Cable LBUS - LBUS (1.5m/5ft)NOTE: Left side: OCU-1 (focus) Right side: Master Grip Zoom Rocker (zoom)
The ARRI Digital Encoder Head is the perfect way to intuitively control the Stabilized Remote Head 360 EVO and SRH-3 and SRH-360. The DEH-1 was specially manufactured according to ARRI specifications, with features such as special damping performance and adjustable pan bars. The DEH-1 uses LBUS communication to control the 360 EVO and SRH-3 and the SRH-360, especially for broadcast applications, but the LBUS also enables the use of Master Grips and the OCU-1 to control focus and zoom. With the DEH-1, you can control all functions of the remote head, as well as focus and zoom, using a single cable.includes:K2.0022594 1x DEH-1 Digital Encoder HeadK2.0009494 1x Master Grip Right Wheel MRW-1K2.0009490 1x Master Grip Left Rocker MLR-1K2.0012919 2x Handgrip Pan Bar Adapter 20mmK2.0006752 1x Cable LBUS - LBUS (0.8m/2.6ft)K2.0006753 2x Cable LBUS - LBUS (1.5m/5ft)NOTELeft side: Master Grip Zoom Rocker (zoom)Right side: Master Grip Wheel (focus)
Ready to work set, based on the second-generation ARRI digital encoder head, DEH-2.Including LBUS controllers, like the OCU-1 for focus and the Master Grip for zoom.As also all needed cables and brackets and mounts.The high-resolution ARRI encoded head for VR, AR and ARRI’s Mixed Reality productions and applications is equipped with absolute encoders providing 4 million counts per turn for both Pan and Tilt. The integrated LBUS communication supports fast and easy system integration in the CSS workflow.An exceptional new fluid module in both Pan and Tilt modes ensures smooth movements, with perfect starts and stops, the drag system allows a wide variety from almost freewheeling in fast action movements to maximum resistance for perfect long focal shoots. Counterbalance performs perfect balance at any angle from 0 to +/- 90 degrees.All operating knobs and levers are conveniently located and easy to reach, with a special care for ergonomics.Includes:K2.0044672 1x DEH-2, Digital Encoder Head 2K2.0020002 1x Operator Control Unit OCU-1 Basic SetK2.0020003 1x OCU-1 Rosette BracketK2.0009490 1x Master Grip Left Rocker MLR-1K2.0048586 2x Cartoni special pan bar 20mmK2.0012919 2x Handgrip Pan Bar Adapter 20mmK2.0006752 2x Cable LBUS - LBUS (0.8m/2.6ft)K2.0006753 2x Cable LBUS - LBUS (1.5m/5ft)Interfaces: 2 x LBUS / 1 x BiSSWeight: 10.5 kg / 23 lbsMinimum Payload Capacity: 3 kg / 7 lbsMaximum Payload Capacity: 30 kg / 66 lbsBowl Diameter: FlatFluid Drag: ContinuousCounterbalance: ContinuousPan Range: 360 degreeTilt Range: +/- 90 degreeTemperature Range: -40 degree - +60 degree / -40 degree F - 140 degree F
Ready to work set, based on the second-generation ARRI digital encoder head, DEH-2.Including LBUS controllers, like the OCU-1 for focus and the Master Grip for zoom.As also all needed cables and brackets and mounts.The high-resolution ARRI encoded head for VR, AR and ARRI’s Mixed Reality productions and applications is equipped with absolute encoders providing 4 million counts per turn for both Pan and Tilt. The integrated LBUS communication supports fast and easy system integration in the CSS workflow.An exceptional new fluid module in both Pan and Tilt modes ensures smooth movements, with perfect starts and stops, the drag system allows a wide variety from almost freewheeling in fast action movements to maximum resistance for perfect long focal shoots. Counterbalance performs perfect balance at any angle from 0 to +/- 90 degrees.All operating knobs and levers are conveniently located and easy to reach, with a special care for ergonomics.Includes:K2.0044672 1x DEH-2, Digital Encoder Head 2K2.0020002 1x Operator Control Unit OCU-1 Basic SetK2.0020003 1x OCU-1 Rosette BracketK2.0009493 1x Master Grip Right Rocker MRR-1K2.0048586 2x Cartoni special pan bar 20mmK2.0012919 2x Handgrip Pan Bar Adapter 20mmK2.0006752 2x Cable LBUS - LBUS (0.8m/2.6ft)K2.0006753 2x Cable LBUS - LBUS (1.5m/5ft)Interfaces: 2 x LBUS / 1 x BiSSWeight: 10.5 kg / 23 lbsMinimum Payload Capacity: 3 kg / 7 lbsMaximum Payload Capacity: 30 kg / 66 lbsBowl Diameter: FlatFluid Drag: ContinuousCounterbalance: ContinuousPan Range: 360 degreeTilt Range: +/- 90 degreeTemperature Range: -40 degree - +60 degree / -40 degree F - 140 degree F
Second generation ARRI digital encoder head, DEH-2.The high-resolution ARRI encoded head for VR, AR and ARRI’s Mixed Reality productions and applications is equipped with absolute encoders providing 4 million counts per turn for both Pan and Tilt. The integrated LBUS communication supports fast and easy system integration in the CSS workflow.An exceptional new fluid module in both Pan and Tilt modes ensures smooth movements, with perfect starts and stops, the drag system allows a wide variety from almost freewheeling in fast action movements to maximum resistance for perfect long focal shoots. Counterbalance performs perfect balance at any angle from 0 to +/- 90 degrees.All operating knobs and levers are conveniently located and easy to reach, with a special care for ergonomics.Interfaces: 2 x LBUS / 1 x BiSSWeight: 10.5 kg / 23 lbsMinimum Payload Capacity: 3 kg / 7 lbsMaximum Payload Capacity: 30 kg / 66 lbsBowl Diameter: FlatFluid Drag: ContinuousCounterbalance: ContinuousPan Range: 360 degreeTilt Range: +/- 90 degreeTemperature Range: -40 degree - +60 degree / -40 degree F - 140 degree F
The Digital Encoder Pedals use LBUS communication to easily integrate into the 360 EVO and SRH-3 and SRH-360 workflows. The Digital Encoder Pedals are the most precise way to control the Stabilized Remote Head 360 EVO and SRH-3 and SRH-360.includes:K2.0039147 1x DEP-1, Host PedalK2.0039149 1x DEP-1, Client PedalK2.0001637 1x Cable RS - RS/PWR IN (0.5m/1.6ft)
The known ARRI wheels have also been optimized for the new type of mounting. The new mounting base with No-Tool Clamp allows the user to place the ARRI Wheel in any desired position.Equiped with the smaller 150mm wheels.includes:K2.0051132 1x DRW-1 Mounting Base 2KK.0021211 1x DRW-1 Digital Remote Wheel, Third Wheel SetK2.0042837 1x CSS Clamp Bridge 52, 19mmFor:TRINITY 2, 360 EVO, SRH-360, SRH-3
Additional third wheel set for the DRW-1 Digital Remote Wheels, Two Wheels Set KK.0021212includes:K2.0019319 1x DRW-1 ModuleN2.25004.A 1x Hand Wheel 150 completeK2.0006751 1x Cable LBUS - LBUS (0.5m/1.5ft)
The known ARRI wheels have also been optimized for the new type of mounting. The new mounting base with No-Tool Clamp allows the user to place the ARRI Wheel in any desired position. Equiped with the bigger 160 wheels.includes:K2.0019319 1x DRW-1 ModuleK2.0051672 1x Hand Wheel 160 completeK2.0019318 1x DRW-1 Modul Mounting BracketK2.0051132 1x DRW-1 Mounting Base 2K2.0042837 1x CSS Clamp Bridge 52, 19mmFor:TRINITY 2, 360 EVO, SRH-360, SRH-3
The EJS-1 external joystick uses the so-called broadcast joystick, known from the SRH-360 & 360 EVO. In addition to pan and tilt, the broadcast joystick offers the option of assigning roll or zoom to the joystick. A button on the upper part of the joystick can be used to trigger pre-programmed functions.includes:K2.0049229 1x EJS-1, External Joystick, BroadcastK2.0006750 1x Cable LBUS - LBUS (0.3m/1ft)K2.0042837 1x CSS Clamp Bridge 52, 19mm
This set combines the new EJS-1 external joystick and the new External Jog-Wheels plus all needed cables and mounting brackets.The EJS-1 external joystick uses the so-called broadcast joystick, known from the SRH-360 & 360 EVO. In addition to pan and tilt, the broadcast joystick offers the option of assigning roll or zoom to the joystick. A button on the upper part of the joystick can be used to trigger pre-programmed functions.In order to provide the operator with additional options to dial in values more quickly and to provide greater flexibility in recalling preprogrammed functions, the external jog-wheels EJW-1 provide three encoder knobs. As usual, both controllers are connected (daisy-chained) to the TRINITY 2 remote control panel (RCP-3) via LBUS cables and can be addressed using the new CSS EVO GUI 3.0 immediately.includes:K2.0049229 1x EJS-1, External Joystick, BroadcastK2.0049230 1x EJW-1, External Jog-WheelsK2.0006750 2x Cable LBUS - LBUS (0.3m/1ft)K2.0042837 2x CSS Clamp Bridge 52, 19mmK2.0047854 1x NATO Accessory Rail NAR-60K2.0049419 1x NATO Rail Clamp NRC-3
The EJS-1 external joystick uses the so-called broadcast joystick, known from the SRH-360 & 360 EVO. In addition to pan and tilt, the broadcast joystick offers the option of assigning roll or zoom to the joystick. A button on the upper part of the joystick can be used to trigger pre-programmed functions.
In order to provide the operator with additional options to dial in values more quickly and to provide greater flexibility in recalling preprogrammed functions, the external jog-wheels EJW-1 provide three encoder knobs. As usual, both controllers are connected (daisy-chained) to the TRINITY 2 remote control panel (RCP-3) via LBUS cables and can be addressed using the new CSS EVO GUI 3.0 immediately.includes:K2.0049230 1x EJW-1, External Jog-WheelsK2.0006750 1x Cable LBUS - LBUS (0.3m/1ft)K2.0042837 1x CSS Clamp Bridge 52, 19mmK2.0047854 1x NATO Accessory Rail NAR-60K2.0049419 1x NATO Rail Clamp NRC-3
The EJS-1 external joystick uses the so-called broadcast joystick, known from the SRH-360 & 360 EVO. In addition to pan and tilt, the broadcast joystick offers the option of assigning roll or zoom to the joystick. A button on the upper part of the joystick can be used to trigger pre-programmed functions.
Set of digital high-resolution controllers for adjusting focus via a focus wheel and zoom via a zoom rocker, based on the LBUS protocol. This allows users to control focus and zoom via LBUS with cforce mini motors, or through the LCUBE CUB-2. Both controllers can also be freely assigned to other functions like iris, roll axis, etc.includes:K2.0019291 1x Focus Knob for SRH Remote Control PanelK2.0019292 1x Zoom Rocker for SRH Remote Control PanelNOTEBoth controllers can be installed by the operator himself, no additional service is required.For 360 EVO and SRH-3 and SRH-360 remote control panel.
The digital focus wheel is an additional high-resolution digital controller for the SRH remote control panel. In general, it is used to control focus via LBUS with cforce mini motors, or through the LCUBE CUB-2. But it can also be freely assigned to other functions such as iris, roll axis, etc.NOTEBoth controllers can be installed by the operator himself, no additional service is required.For 360 EVO and SRH-3 and SRH-360 remote control panel.
New LBUS-based Microforce joystick for TRINITY 2, with one joystick and three freely assignable buttons.NOTEOne joystick, three buttonsincludes:K2.0041091 1x MGT-1, Master Grip TRINITY 2, one controllerK2.0044234 1x 12G HD SDI BNC Cable, 0,84m/33inK2.0043861 1x TRINITY 2 Joystick Cable, 75cm/29.5inK2.0038998 1x MTG Monitor Pwr, Lemo 0B, 2-pinK2.0038999 1x MTG Monitor Pwr, Lemo 0B, 5-pinNOTETo complete the initial order, at least one of the mandatory joystick sets must be ordered.
New LBUS based Micro Force joystick for TRINITY 2, with two joysticks and six freely assignable buttons.NOTETwo joysticks, six buttonsincludes:K2.0041089 1x MGT-2, Master Grip TRINITY 2, two controllersK2.0044234 1x 12G HD SDI BNC Cable, 0,84m/33inK2.0043861 1x TRINITY 2 Joystick Cable, 75cm/29.5inK2.0038998 1x MTG Monitor Pwr, Lemo 0B, 2-pinK2.0038999 1x MTG Monitor Pwr, Lemo 0B, 5-pinNOTETo complete the initial order, at least one of the mandatory joystick sets must be ordered.
The Microforce Joystick is a high-resolution 2-axis controller for the SRH remote control. The Microforce Joystick offers a highly precise and tactile, optimized control of the pan and tilt axis of the remote head.For 360 EVO and SRH-3 and SRH-360NOTETo complete the initial order, at least one of the mandatory joystick sets must be ordered. The controller can be installed by the operator themselves, no additional service is required.
The RCP-2 Mounting adapter allows mounting the RCP 2 EVO remote control panel, and to position freely and flexible the ARRI wheels, as well as the joystick, and the external jog-wheels onto the RCP-3, Controller, 19 mm mounting set. (KK.0051503)includes:K2.0052699 1x RCP-2-Rod Mounting Adapter, incl. ScrewsK2.0042837 2x CSS Clamp Bridge 52, 19mmNOTEOnly in combination with KK.0052698 RCP-3, Controller, 19mm Mounting Set
To be able to arrange and mount the TRINITY 2 remote control panel (RCP-3), as well as the joystick, the jog-wheels and the ARRI wheels quickly and flexibly to each other, we have developed a new mounting system based on 19mm tubes and no-tool clamps. The RCP-3, Controller, 19 mm mounting set uses a tool-free Mitchell mount quick release and can be attached to any flat tripod.includes:K2.0049453 1x Mitchell Wedge Lock SetK2.0050433 1x CSS Mitchell Base PlateK2.0049885 2x CCB-2, CSS Clamp Bridge-2, 52, 19mmK2.0040791 1x Support Rods 430mm, 16.9in, 19mm
Standard fully digital high-resolution 2-axis joystick for the SRH remote control. The Standard Joystick offers a highly precise and tactile, optimized control of the pan and tilt axis of the remote head.For 360 EVO and SRH-3 and SRH-360NOTETo complete the initial order, at least one of the mandatory joystick sets must be ordered. The controller can be installed by the operator themselves, no additional service is required.
The digital zoom rocker is an additional high-resolution digital controller for the SRH remote control panel. In general, it is used to control zoom via LBUS with cforce mini motors, or through the LCUBE CUB-2. But it can also be freely assigned to other functions such as roll axis, etc.NOTEBoth controllers can be installed by the operator himself, no additional service is required.For 360 EVO and SRH-3 and SRH-360 remote control panel.
