This baseplate fits to ALEXA Mini/Mini LF and is the common interface to the Compact Bridge Plate CBP-1/CBP-2 and Stabilizer Adapter Mount SAM-2. The BUD-2 is available separately to complement Stabilizer plates for CBP 225mm/9in, 355mm/14in and 450mm/18in.
The Compact Lens Support CLS-1 fits directly to the front groove of the Stabilizer Plate for CBP 450mm/18in and 355mm/14in to supports heavier prime lenses and smaller zooms such as the Signature Zoom 16-32mm. With lenses with support height reach under the level of the stabilizer mount, The Stabilizer Systems Bracket SSB-2 19mm or 15mm is advised.
The Dovetail Utility Base DUB-1 allows camera rigs using ARRI CSS standard dovetails (QL-plates, SAM plates, Stabilizer Plate for CBP...) to mount to any “touch and Go 35” support for camera prep or quick switch from ARRI CSS to fluid heads. The DUB-1 features a 20mm rise to leave room for lens motor brackets and cables.Length: 144mm / 5,6inchWeight: 475g / 16,7oz
The DUB-2 is a connecting piece for cameras rigged for stabilizers such as Artemis 1 as well as Tiffen or GPi Pro stabilizers. The DUB-2 allows cameras to be swiftly mounted to the back of a film cart for prep, or on a fluid head for an quick shot.
The DUB-3 is the compact version of the Dovetail Utility Base DUB-1. As with the DUB-1, the tool-free clamping mechanism of the DUB-3 TRINITY 2 allows the mounting of all available SAM dovetail plates, such as SAM Zero, SAM 1, SAM 2, etc.For TRINITY 2 and as upgrade to TRINITY Gen.1 with quick lock mechanism
The DUB-4 Dovetail Utility Base 4, is an alternative dovetail clamp mechanism for the top stage for the ARTEMIS 2. The ARTEMIS 2 Top Stage uses the SAM plates by default. However, if the ARTEMIS owner or operator prefers to continue using the old and slightly wider dovetail plates, he or she can convert the top stage of the ARTEMIS 2 to the old system using the DUB-4 Dovetail Utility Base 4.
The set is optimized for long lenses such as the Signature Zoom 65-300mm mounted to ALEXA Mini/Mini LF in ARRI CSS products.Included is a long Stabilizer Plate for CBP 450mm/18in that allows the camera to be attached and balanced to ARRI TRINITY, MAXIMA and 360 EVO, SRH-3 and SRH-360. The adjustable Stabilizer Systems Bracket SSB-2 15mm offers standard rod support for traditional 15mm Studio lens support such as the ARRI LS-10, as well as support for any optically centered accessory, such as rain deflectors, ring lights and matte boxes. The Compact Lens Support CLS-1 fits directly to the front groove of the Stabilizer Plate for CBP 450mm/18in and supports smaller zooms such as the Signature Zoom 16-32mm.Includes:K2.0038618 1x Stabilizer System Bracket SSB-2 15mmK2.0039089 1x Compact Lens Support CLS-1K2.0038536 1x Stabilizer Plate for CBP 450mm/18inK2.0038783 1x LLS-1 Lens BridgeFor TRINITY 2, ARTEMIS 2, TRINITY Gen. 1, 360 EVO, SRH-3, SRH-360, MAXIMA
The set is optimized for long lenses such as the Signature Zoom 65-300mm mounted to ALEXA Mini/Mini LF in ARRI CSS products.Included is a long Stabilizer Plate for CBP 450mm/18in that allows the camera to be attached and balanced to ARRI TRINITY, MAXIMA and 360 EVO, SRH-3 and SRH-360, an adjustable Stabilizer Systems Bracket SSB-2 19mm, which offers standard rod support for traditional 19mm Studio lens support such as the ARRI LS-9, as well as support for any optically centered accessory, such as rain deflectors, ring lights and matte boxes. The Compact Lens Support CLS-1 fits directly to the front groove of the Stabilizer Plate for CBP 450mm/18in and supports smaller zooms such as the Signature Zoom 16-32mm.Includes:K2.0038537 1x Stabilizer System Bracket SSB-2 19mmK2.0038536 1x Stabilizer Plate for CBP 450mm/18inK2.0039089 1x Compact Lens Support CLS-1K2.0038783 1x LLS-1 Lens BridgeFor TRINITY 2, ARTEMIS 2, TRINITY Gen. 1, 360 EVO, SRH-3, SRH-360, MAXIMA
The SAM-1 offers optical-centered mounting of ALEXA Classic, XT, SXT and LF cameras (not ALEXA Studio, ALEXA M or ALEXA 65) on the ARRI Trinity and MAXIMA system. The SAM-1 is also compatible with third-party stabilizer systems fitted with a standard 60 mm dovetail.For TRINITY 2, ARTEMIS 2, TRINITY Gen. 1, 360 EVO, SRH-3, SRH-360, MAXIMA
The SAM-2 offers optical-centred mounting of ALEXA Mini cameras to the ARRI Trinity and MAXIMA systems. The SAM-2 is also compatible with third party stabilizer systems fitted with a standard 60mm dovetail.For TRINITY 2, ARTEMIS 2, TRINITY Gen .1, 360 EVO, SRH-3, SRH-360, MAXIMA
Stabilizer Adapter Mount SAM-2 for ALEXA Mini with a rod mounting bracket and two single rods ⌀19mm designed to support lens motors driving Ultra primes and Master Prime lensesincludes:K2.0014215 1x Stabilizer Adapter Mount SAM-2 for ALEXA MiniK2.0006186 1x Rod Mounting Bracket RMB-3K2.0014960 1x Single Support Rod 90mm, 3.5in, 19mmK2.0014961 1x Single Support Rod 150mm, 5.9in, 19mmFor TRINITY 2, ARTEMIS 2, TRINITY Gen. 1, 360 EVO, SRH-3, SRH-360, MAXIMA
The SAM-3 offers optical-centred mounting of AMIRA cameras to the ARRI Trinity and MAXIMA systems. The SAM-3 is also compatible with third party stabilizer systems fitted with a standard 60mm dovetail.For TRINITY 2, ARTEMIS 2, TRINITY Gen. 1, 360 EVO, SRH-3, SRH-360, MAXIMA
Stabilizer Adapter Mount SAM-3 for AMIRA with a rod mounting bracket and two single rods ⌀19mm designed to support lens motors driving Ultra primes and Master Prime lensesincludes:K2.0014630 1x Stabilizer Adapter Mount SAM-3 for AMIRAK2.0006186 1x Rod Mounting Bracket RMB-3K2.0014960 1x Single Support Rod 90mm, 3.5in, 19mmK2.0014961 1x Single Support Rod 150mm, 5.9in, 19mmFor TRINITY 2, ARTEMIS 2, TRINITY Gen. 1, 360 EVO, SRH-3, SRH-360, MAXIMA
The Stabilizer Adapter Mount SAM-4 allows some non-ARRI cameras equipped with ARRI PCA to transit rapidly between fluid heads to stabilizer units from ARRI CSS. SAM-4 can be sandwiched to classic stabilizer plates, such as GPI Pro, etc.Range of suitable cameras include Canon C300, C500, Sony Venice (note: the Venice is top heavy with SAM-4 in TRINITY), ALEXA Mini with Broadcast Plate, RED DSCM2 with Broadcast Plate (note: top heavy in TRINITY)for TRINITY 2, ARTEMIS 2, TRINITY Gen. 1, 360 EVO, SRH-3, SRH-360, MAXIMA
The Stabilizer Adapter Mount SAM-Zero is the standard camera plate for most ARRI Camera Stabilizer systems products. The 254mm (10”) plate will allow most camera featuring 3/8 in threads on the base to be safely mounted to ARRI TRINITY 2, TRINITY Gen.1, ARTEMIS 2, 360 EVO, SHR-3, SRH-360 and MAXIMA.includes: 2x 3/8 ScrewsLength: 254mm / 10inchWeight: 150g / 5.29ozFor TRINITY 2, ARTEMIS 2, TRINITY Gen. 1, 360 EVO, SRH-3, SRH-360, MAXIMA
This Stabilizer Plate helps balance ALEXA Mini/Mini LF cameras on stabilizer systems with heavier prime lenses or shorter zooms that require support. A Balance Utility Dovetail BUD-2 is required if not provided in the camera set. To support smaller zoom, the Compact lens Support CLS-1 is available. For larger optics with support height reaching under the level of the stabilizer mount, the Stabilizer Systems Bracket SSB-2 19mm or 15mm is advised.For TRINITY 2, ARTEMIS 2, TRINITY Gen. 1, 360 EVO, SRH-3, SRH-360, MAXIMA
The Stabilizer Plate for CBP 450mm/18in is a long support plate designed to support ALEXA Mini/Mini LFand longer cinema optics, such as Signature Zooms, on ARRI CSS products.The Stabilizer Plate for CBP 450mm/18in is fitted with a slot designed for the CompactLens Support CLS-1 (K2.0039089) aimed at providing built-in support to more compactlenses for use with Trinity or Artemis.Stabilizer Plate for CBP 450mm/18in is compatible with Stabilizer System Bracket SSB-2 19mm (K2.0038537) studio and 15mm (K2.0038618) studio.It is a part of KK.0038972 Long Stabilizer Mount 19mm Mini/Mini LF and KK.0038971 Long Stabilizer Mount 15mm Mini/Mini LF.For TRINITY 2, ARTEMIS 2, TRINITY Gen. 1, 360 EVO, SRH-3, SRH-360, MAXIMATRINITY2, ARTEMIS 2, SRH-3, SRH-360, TRINITY Gen.1
The Stabilizer System Bracket SSB-2 15mm studio is a adjustable rod console for CSSplates aimed at cameras rigged with long lenses and traditional studio lens supports e.g. LS-9, LS-10 as well as matte boxes, rain deflectors, ring lights and other accessories that require centering on studio rod supports.If no rod-mounted accessories (e.g. Rain deflectors, mattebox, lens motors) are required in front of the lens, the Signature Zooms 16-32, 24-75 and 45-135 can be supported with the Compact Lens Support CLS-1 K2.0039089 and the Stabilizer Plate For CBP-450MM/18IN K2.0038536. Signature Zoom 60-300 requires an SSB-2 19/15 and a lens support such as LS-9/10.It is a part of KK.0038971 Long Stabilizer Mount 15mm Mini/Mini LF.
The Stabilizer System Bracket SSB-2 19mm studio is a adjustable rod console for CSSplates aimed at cameras rigged with long lenses and traditional studio lens supports e.g. LS-9, LS-10 as well as matte boxes, rain deflectors, ring lights and other accessories that require centering on studio rod supports.If no rod-mounted accessories (e.g. Rain deflectors, mattebox, lens motors) are required in front of the lens, the Signature Zooms 16-32, 24-75 and 45-135 can be supported with the Compact Lens Support CLS-1 K2.0039089 and the Stabilizer Plate For CBP-450MM/18INK2.0038536. Signature Zoom 60-300 requires an SSB-2 19/15 and a lens support such as LS-9/10.It is a part of KK.0038972 Long Stabilizer Mount 19mm Mini/Mini LF.
